1200mm hydraulic casing oscillator with euro tier 5 diesel engine power pack for cased bored pile foundation work used for pull out double wall casing
Extraction of double wall casing pipe with 1200mm hydraulic casing oscillator for cased bored pile foundation work
Foundation drill rig type casing oscillator hydraulic type 1200mm connect on bauer-bg28 drill rig with euro tier5 emissions power pack
Foundation drill rig type hydraulic casing oscillator 1200mm connect on san-y sr285 drill rig with euro tier5 emissions diesel engine power pack used for pull out double wall casing pipe
Short typer casing oscillator 1200mm connect on soilmec drill rig with euro tier5 emissions diesel engine power pack for cased bored pile foundation work
Short version drill rig casing oscillator connected on liebherr-LB28 rotary drill rig for cased piling foundation work
1300mm hydraulic casing oscillator connected on bau-er bg28 rotary drill rig for cased bored pile foundation work
Foundation drill rig casing oscillator 1300mm used for drop down and pull out double wall casing during secant pile foundation work
Foundation drill rig casing oscillator 1200mm used for drop down and pull out double wall casing during secant pile foundation work
Foundation drill rig casing oscillator 1500mm used for drop down and pull out double wall casing during secant pile foundation work
2000mm hydraulic casing oscillator connected on bau-er bg28 rotary drill rig for cased bored pile foundation work
1,specification of 1200mm hydraulic casing oscillator
|
MODEL： |
BCG1200D |
REMARK |
|
CASING OD (mm) |
600～1200 |
|
|
MAX LIFT FORCE (kN) |
1200 |
|
|
OSCILLATE ANGEL (°) |
18° |
|
|
TORQUE (KN·m) |
1250 |
|
|
STROKE（mm） |
450 |
|
|
CLAMP FORCE（kN） |
1100 |
|
|
OVER SIZE (L×W×H)(mm) |
3200×2250×1600 |
|
|
WEIGHT (T) |
10 |
2,specification of casing oscillator power pack
|
MODEL： |
DL160 |
REMARL |
|
ENGINE MODEL： |
QSB4.5-C130 |
|
|
DIESEL ENGINE kW |
100 |
|
|
OUT CAPACITY l/min |
150 |
|
|
WORKING PRESSURE：MPa |
25 |
|
|
OIL TANK L |
800 |
|
|
OVER SIZE(L×W×H)(mm) |
3000×1900×1700 |
|
|
WEIGHT (kg) |
2500 |
NOT INCLUDE OIL |
Casing Oscillator is a high-performance machine designed for efficient soil mixing and foundation construction. It features a maximum torque of 300 kN·m and an oscillation frequency range of 0 to 60 rpm, allowing for precise and adaptable operations. The casing oscillator's robust design and powerful performance make it suitable for various foundation projects, including deep mixing and soil stabilization
Tianjin huachang xingye technology co ltd casing Oscillator is an advanced and highly reliable oscillatory drilling rig designed for the most demanding foundation engineering and soil improvement projects. With its cutting-edge technology, the combines power, precision, and efficiency to offer exceptional performance in heavy-duty applications. is engineered to optimize productivity and reduce operational costs, making it an essential tool for a wide range of large-scale construction and infrastructure projects.
Featuring an advanced hydraulic system and an intuitive control interface, the casing Oscillator is capable of handling a wide range of soil conditions, from soft ground to more challenging, hard soils. Its enhanced stability, high torque output, and robust design ensure smooth operation, even in the toughest environments. This versatile equipment is ideal for use in urban, industrial, and large civil engineering projects.
Key Features:
High Torque Output: tianjin huachang xingye technology co ltd offers exceptional torque performance for efficient deep foundation drilling and soil improvement.
Advanced Hydraulic System: Features an advanced hydraulic system for smooth, reliable, and precise operation in various ground conditions.
Compact and Robust Design: The rig’s compact design allows for optimal maneuverability in confined spaces while maintaining stability during operation.
Enhanced Safety Features: Equipped with overload protection and advanced monitoring systems to ensure maximum safety for operators.
Precise Control: casing oscillator provides easy-to-use, precision controls for efficient operation and high productivity in challenging environments.
Durability: Built with high-quality materials and engineering standards to ensure long-lasting performance under extreme working conditions.
Versatile Application: Capable of handling different types of soil and foundation depths, offering versatility across multiple construction sectors.
Technology Integration: The rig is equipped with intelligent monitoring systems that collect real-time performance data to optimize operations and prevent issues.
➤ Applications:
Large-Scale Foundation Construction: Ideal for constructing deep foundation piles, including those for high-rise buildings, bridges, and tunnels.
Soil Improvement and Stabilization: Original for soil treatment and stabilization to ensure strong and reliable foundations in soft or unstable ground.
Urban Development Projects: Perfect for foundation work in congested urban areas, where space and efficiency are critical.
Bridge and Infrastructure Projects: Essential for creating secure and stable foundations for major infrastructure, including bridges, highways, and railways.
Geotechnical Investigations: Original for conducting deep soil and geotechnical investigations, offering precise data for planning and design.
The tianjin huachang xingye technology co ltd casing Oscillator is the ultimate solution for contractors and engineers in need of a powerful, efficient, and versatile tool for complex foundation engineering and soil improvement tasks. Built to deliver outstanding performance and reliability, it ensures a seamless operation in even the most challenging working environments.
1. What is the tianjin huachang xingye technology co ltd Oscillator original for?
Tianjin huachang xingye technology co ltd casing Oscillator is a heavy-duty piece of equipment designed for efficient pile driving and soil stabilization in deep foundation construction projects. ➤ Perfect for large infrastructure projects such as bridges, marine structures, and high-rise buildings. ➤ Original to improve soil compaction and provide enhanced foundation support.
2. What are the key features of the tianjin huachang xingye technology co ltd Oscillator?
➤ High-frequency oscillation for fast and precise pile driving.
➤ Robust design suited for both land and marine construction.
➤ Powered by an advanced hydraulic system for consistent power delivery.
➤ Designed to operate in the most challenging soil and environmental conditions.
The tianjin huachang xingye technology co ltd casin Oscillator is capable of reaching a maximum depth of 75 meters, making it ideal for deep foundation work in a variety of soil conditions.
4. What is the maximum pile diameter the casing oscillator can handle?
The tianjin huachang xingye technology co ltd BCG 1500 can drive piles with a maximum diameter of up to 1500 mm making it perfect for large-scale construction projects that require large-diameter piles.
What type of engine powers the TIANJIN HUACHANG XINGYE TECHNOLOGY CO LTD CASING Oscillator?
The TIANJIN HUACHANG XINGYE TECHNOLOGY CO LTD BCG CASING Oscillator is powered by a high-performance diesel engine, HAVE EURO TIER3 EMISSIONS DIESEL ENGINE POWER PACK , EURO TIER5 DIESEL ENGINE POWER PACK providing the necessary energy to efficiently drive piles and stabilize soil in demanding construction environments.
